Description
Features
– Rugged Operator Friendly Design
– Durable Polypropylene Construction
– 4 Position Plating With Traversing Cathode (6-position also available)
– 5 Titanium Basket/Static Anode
– Low Flow Solution Circulation
– Low Current Plating For High Surface Quality
– Programmable Control System
– Precision Temperature Control
– Integrated Solution Filtration
– Semi-Enclosed Clean Working Area
– Air Extraction Ready
– Lighted Work Area
Specifications
Dimensions
Length 87 in.
Depth 36 in.
Height 78 in.
Construction
Shell Material Polypropylene
Plumbing Polypropylene/PVC
Electrical Input
Voltage 208 to 240 VAC
Phase 1 Ph
Freq. 50/60 Hz.
Max. Current 20 A.
Plating Power Supply
Max. Current 2 x 50 Amps (50 amps per side)
Max. Voltage 10 VDC (per side)
Heating System
Temperature Control +/-1 degree F/C
Wattage 6 kW
