Description
Features
• Electro-clean/passivation programmable anodic/cathodic cycling for anodic passivation and cathodic cleaning/activation of nickel and other metals
• Up to 20 amps programmable current
• Single cell precision electro-cleaning
• Up to 14×14″ cleaning surface area
• Stainless-steel electrode
• Chemical passivation dip and prep
• Integrated temperature control/ heater
• High flow circulation
• Reversible polarity for both passivation and activation
• “Wet” feature sink for prep and rinsing with foot-controlled faucet
SPECIFICATIONS
Dimensions
Length
Depth
Height
Construction
Shell Material Polypropylene
Plumbing Polypropylene/PVC
Electrical Input
Voltage 208 to 240 VAC
Phase 1 phase
Freq. 50/60 hz.
ElectroClean Current 0-25 Amps
Plating Current Step Size 0.1 Amps
Maximum Voltage 12 VDC
Capacity
Maximum Cleaning Area 200 mm x 200 mm (8×8″)
Maximum Solution Volume 16 liters (~4 gallons)
Pump/ Filtration
Pump Size 1/16th HP
Heater 1 kW Teflon Coated
Filter 1-10″ DOE 0.5 to 5 micron
